POWER
|
UPS Capacity |
1000 VA / 600 W
|
INPUT
|
Input Voltage Range
|
140 VAC to 290 VAC; 85 VAC to 150 VAC
|
|
Input Frequency |
50/60 Hz self-adaptive
|
|
Plug Type |
UK TYPE G; Type B (NEMA 5-15) ; Schuko
|
OUTPUT
|
Output Frequency |
50/60 Hz ± 0.5 Hz self-adaptive
|
Network
|
Output Voltage Range |
210 VAC to 235 VAC;110 VAC to 125 VAC
|
|
Transfer Time |
≤ 10 m s
|
|
Waveform |
PWM |
|
Outlet Type |
Universal
|
|
Outlet Number |
2 |
BATTERY
|
Battery Type |
12 V/9 Ah, lead-acid battery
|
|
Recharge Time |
4-6 hours recover to 90% capacity
|
|
Typical Backup Time |
Run time at 60w: 60 min
Run time at 150w: 15 min
Run time at 300w: 2 min
|
Interface
|
Communicate Ports |
NO
|
Protection
|
Full Protection |
Surge protection, Overload protection, Discharge protection, Short circuit protection
|
Indicator
|
Display |
LED indicator
Working Mode (AC Mode): Solid green
Charging Mode (DC Mode): Solid red
Overloading Mode: Flashing yellow
|
|
Alarm |
Charging Mode (DC mode): Sounding every 8 seconds
Low Battery: Sounding every second
Overloading Mode: Sounding every 0.5 seconds
Fault: Continuously sounding
|
|
General
|
Operating Temperature |
0 °C to 40 °C (32 °F to 104 °F）
|
|
Operating Humidity |
30% to 90% (non-condensing)
|
|
Dimension |
274 mm × 95 mm × 139 mm (10.79" × 3.74" × 5.47")
|
