Camera
|
Image Sensor |
1/2.8" Progressive Scan CMOS |
|
Max. Resolution |
3840 × 2160 |
|
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
|
Shutter Time |
1/3 s to 1/100,000 s |
|
Day & Night |
IR cut filter |
|
Angle Adjustment |
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
| Lens |
Focal Length & FOV |
2.8 mm, horizontal FOV 108°, vertical FOV 59°, diagonal FOV 127° 4 mm, horizontal FOV 88°, vertical FOV 44°, diagonal FOV 105° 6 mm, horizontal FOV 54°, vertical FOV 29°, diagonal FOV 63°
|
|
Lens Type |
Fixed focal lens, 2.8, 4, and 6 mm optional
|
|
Lens Mount |
M12 |
|
Iris Type |
Fixed |
|
Aperture |
F1.6
|
|
Depth of Field
|
2.8 mm: 1.7 m to ∞ 4 mm: 2.6 m to ∞ 6 mm: 5.8 m to ∞
|
| DORI |
DORI |
2.8 mm, D: 84 m, O: 33 m, R: 16 m, I: 8 m 4 mm, D: 117 m, O: 46 m, R: 23 m, I: 11 m 6 mm, D: 176 m, O: 70 m, R: 35 m, I: 17 m
|
| Illuminator |
Supplement Light Type |
IR, White Light |
|
Supplement Light Range |
Up to 40 m |
|
Smart Supplement Light |
yes
|
|
IR Wavelength |
850 nm
|
| Video |
Main Stream
|
50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
|
Third Stream
|
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
|
|
Video Compression
|
Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
|
|
Video Bit Rate |
32 Kbps to 16 M bps
|
|
H.264 Type |
Baseline Profile, Main Profile, High Profile
|
|
H.265 Type |
Main Profile
|
|
Scalable Video Coding (SVC) |
H.264 and H.265 encoding
|
|
Bit Rate Control |
CBR,VBR
|
|
Region of Interest (ROI) |
1 fixed region for main stream and sub-stream
|
|
Target Cropping |
yes
|
| Audio |
Audio Compression |
-2U: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
|
|
Audio Bit Rate |
-2U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
|
|
Audio Sampling Rate |
-2U: 8 kHz/16 kHz/32 kHz/48 kHz
|
|
Environment Noise Filtering |
-2U: Yes
|
|
Network
|
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, Web Socket, Web Sockets
|
|
|
Simultaneous Live View |
Up to 6 channels
|
|
|
API |
Open Network Video Interface (Profile S, Profile G),ISAPI,SDK,ISUP
|
|
Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
|
|
User/Host |
Up to 32 users
3 user levels: administrator, operator, and user
|
|
Client |
iVMS-4200,Hik-Connect,Hik-Central
|
|
Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
|
|
Web Browser |
Plug-in required live view: IE 11,
Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,
Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
|
|
|
Image Parameters Switch |
YES
|
|
Day/Night Switch |
Day, Night ,Auto, Schedule
|
|
Image Settings |
Rotate mode
|
|
Wide Dynamic Range (WDR) |
120 dB
|
|
SNR |
≥ 52 dB
|
|
Image Enhancement |
BLC,HLC,3D DNR
|
|
|
Privacy Mask |
8 programmable polygon privacy masks
|
| Interface |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port
|
|
On-Board Storage |
Built-in memory card slot, support microSD/micro SDHC/micro SDXC card, up to 512 GB
|
|
Reset Key |
YES
|
|
Audio |
Built-in Microphone:
-2U: Dual Array Microphone
|
| Event |
Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm, exception
|
|
Smart Event
|
Unattended baggage detection, object removal detection,
Face detection
|
|
Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger recording, trigger capture
|
|
Deep Learning Function
|
Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
|
|
General
|
Power |
12 VDC ± 25%, 0.5 A, max. 6 W, reverse polarity protection,Ø5.5 mm coaxial power plug,
PoE: IEEE 802.3af, Class 3, max. 7.5 W
|
|
Material |
Metal
|
|
Dimension |
Ø74.4 mm × 176.3 mm (Ø2.93" × 6.94")
|
|
Package Dimension |
234 mm × 120 mm × 117 mm (9.21" × 4.72" × 4.61")
|
|
Weight |
Approx. 515 g (1.1 lb.)
|
|
With Package Weight |
Approx. 760 g (1.7 lb.)
|
|
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
|
|
General Function |
Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding
|
| Approval |
EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
|
|
Safety
|
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1
|
|
Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
|
|
Protection |
|
