Description
178° ultra-wide view screen.
3D noise reduction.
Low blue light design for eye care.
Dual interface of HDMI and VGA.
Support VESA wall mount.
Model DS-D5032F3-1P0S
Display
Screen Size 32 inch
Active Display Area 698.4 (H) mm × 392.85 (V) mm
Resolution 1920 × 1080
Backlight D-LED
Pixel Pitch 0.12125 (H) mm × 0.36375 (V) mm
Brightness 300 cd/m²
Viewing Angle 178° (H)/178° (V)
Color Depth 8 bit
Contrast Ratio 4000:1
Response Time 8 ms
Refresh Rate Typ. 60 Hz, Max. 75 Hz
Haze Haze 2%
Reliability 7 × 12 H
Color Gamut 72% NTSC
Interface
Video & Audio Input VGA × 1, HDMI 1.4 × 1, Audio Output × 1
Video & Audio Output Speaker(8 Ω 10 W) × 2
Power
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption ≤ 48 W
Standby Consumption ≤ 0.5 W
Working
Environment
Working Temperature 0 °C to 40 °C (32 °F to 104 °F)
Working Humidity 20% RH to 90% RH (Non-Condensing)
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 10% RH to 90% RH (Non-Condensing)
General
Casing Material Plastic
VESA 100 mm × 100 mm (4 - M6 × 10 mm)
Bezel Width 16.7 mm (top/left/right), 20.5 mm (bottom)
Product Dimensions (W × H × D)
With base: 735.08 (W) mm × 489.16 (H) mm × 207.95 (D) mm
(28.94'' × 19.26'' × 8.19'')
Without base: 735.08 (W) mm × 433.46 (H) mm × 80.19 (D) mm
(28.94'' × 17.07'' × 3.16'')
Package Dimensions (W × H × D) 808 (W) mm × 510 (H) mm × 140 (D) mm (31.81'' × 20.08'' × 5.51'')
Net Weight 4.55 ± 0.5 kg (10.03 ± 1.10 lb.)
Gross Weight 6.1 kg ± 0.5 kg (13.45 ± 1.10 lb.)
Packing List
Monitor × 1, Base component × 1, HDMI cable (1.5 m) × 1, User manual × 1,
Multilingual manual × 1, remote control × 1, Base screw × 6, Wall-mount
screw × 4
Remarks
The base is included by default.
The product appearance and parameters in this specification may vary from
your actual device. Please consult our local sales staff for further
information
